Salamander 2.4 Bar Single Universal

This premium 2.4 bar single ended pump will quietly and efficiently boost the hot or cold water supplies to your shower, wash basin, bath and kitchen taps in a negative head or positive head gravity fed installation.

For maintained pressure at higher flow rates, you need one of our Right Pumps. The centrifugal impeller means these pumps offer an extra boost, and are quiet with it.

• Quiet - only 52dBA*
• Patented technology
• AV couplers included
• Continuously rated motor - runs as long as it needs to

• This product was formerly known as ESP80 CPV.
• The RP80SU pump is a 2.4 bar single centrifugal shower pump suitable for boosting hot or cold water performance in a gravity fed, negative or positive head system. This pump can be used with a variety of applications, including a single wash basin, bath and kitchen taps. It is also suitable for hot water to showers or mixers when the cold is from the mains water. AV couplers with isolating valves are included.

Guarantee	3 years
WRAS Approval	1810090
Pump Type	Centrifugal
Noise	52dBA*
Mechanical Seal	Nitrile/Carbon/Ceramic
Anti-vibration feet	Yes
Inlet isolators	Yes
Flexible Hoses	2
Pressure @ closed head	2.4 bar
Pressure @ 8lpm	2.3 bar
Pressure @ 16lpm	2.1 bar
Maximum water Temperature	65°C
Pump connections	3/4" BSP
Pressure vessel air pre-charge	18 psi
Hose connections (UK model)	3/4" female x 22 mm push-fit x 280 mm long, isolating valves on all hoses
Hose connections (ROI model)	3/4" female x 21mm push-fit x 280 mm long, isolating valves on all hoses
Motor type	A.C Induction
Motor duty rating	Continuously rated
Power supply	230V
Current (full load)	1.75 amps
Power consumption	400 watts
Fuse rating	3 Amps
Power cable (pre-wired)	1.5 metres
Enclosure protection (IP rating)	IPX2
Length	273 mm
Width	148 mm
Height (Excluding hoses)	317 mm
Weight (Excluding hoses)	6.69 kg

Technical Specifications

Manufacturer Part Number

RP80SU
